| Quantity: | |
|---|---|
Free Spare Parts
1 Year
<10m
100-200 L/min
Motor
Plastic
BDP350
Single-stage Pump
Liquid Pumps
Electric
Electric Pump
Submersible Pump
Submersible Pump, Sewage Pump
Domestic
Sewage Pumps
Wear Pump
Centrifugal Pump
CE GS RoHS PAHs
Carton
5.2kg
MAXIS
China
8413709990
500000PCS/Year
Available | Customized Request
Application
1. Can be used to transfer clean or slightly dirty water or other liquids similar to water in physical and chemical properties
2. Suitable to be immersed in water for lifting water from the well or the pool, and draining water from the basement.
Pump
Techenical Data | Model | Power | Max Flow | Max Head | Max Depth | Outlet | Max Grain size | Protection rating | |
| BDP350 | 350W | 7000 L/H | 117 L/Min | 5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP450 | 400W | 8000 L/H | 133 L/Min | 5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP500 | 500W | 10000 L/H | 167 L/Min | 6 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BPD550 | 550W | 12500 L/H | 208 L/Min | 7 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BPD650 | 650W | 13000 L/H | 217 L/Min | 7.5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP750 | 750W | 14000 L/H | 233 L/Min | 8 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP850 | 850W | 15000 L/H | 250 L/Min | 8.5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP900 | 900W | 17000 L/H | 284 L/Min | 9 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP1100 | 1100W | 18000 L/H | 300 L/Min | 9.5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
Application
1. Can be used to transfer clean or slightly dirty water or other liquids similar to water in physical and chemical properties
2. Suitable to be immersed in water for lifting water from the well or the pool, and draining water from the basement.
Pump Techenical Data | Model | Power | Max Flow | Max Head | Max Depth | Outlet | Max Grain size | Protection rating | |
| BDP350 | 350W | 7000 L/H | 117 L/Min | 5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP450 | 400W | 8000 L/H | 133 L/Min | 5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP500 | 500W | 10000 L/H | 167 L/Min | 6 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BPD550 | 550W | 12500 L/H | 208 L/Min | 7 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BPD650 | 650W | 13000 L/H | 217 L/Min | 7.5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP750 | 750W | 14000 L/H | 233 L/Min | 8 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP850 | 850W | 15000 L/H | 250 L/Min | 8.5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP900 | 900W | 17000 L/H | 284 L/Min | 9 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
| BDP1100 | 1100W | 18000 L/H | 300 L/Min | 9.5 M | 7 M | 1-1/4'' | 1/5/35mm | IPX8 |
